NAAKUU 3P Miniature Circuit Breaker NKM1-63H C20 3/15/20 Amp MCB For Electrical Safety
NAAKUU 3P Miniature Circuit Breaker NKM1-63H C20 3/15/20 Amp MCB For Electrical Safety
| Categories | Mini Circuit Breaker |
|---|---|
| Brand | NAAKUU Electrical Equipment Manufacturer |
| Model | NKM1-63H 3P |
| Colar：Customized | Rated Current ：1-63A |
| Rated Volatge ：230/400V | Breaking Capacity ：4.5kA/6kA |
| Mechinical Life：20000 Times | Curve Type：C |
| Terms of Payment | L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal |
| Update Time | Nov 18,2024 |
Overload Protection Short Circuit Protection
The NKM1-63H is a mini circuit breaker designed for reliable AC power protection. It comes in 1P, 2P, 3P, and 4P models with ratings to 63A, ensuring electrical safety and quality performance.NKM1-63H Mini circuit breakers (MCB) ensure electrical safety in homes, offices and other buildings as well as for industrial applications by protecting electrical installations against overloads and short circuits. Once a fault is detected, the miniature circuit breaker automatically switches off the electrical circuit to prevent damage to wires and to avoid the risk of fire. Warranting reliability and safety for people and assets, MCBs are equipped with two tripping mechanisms: the delayed thermal tripping mechanism for overload protection and the magnetic tripping mechanism for short circuit protection.
Model | NKM1-63H |
Type | MCB |
Pole | 1P/2P/3P/4P |
Rated Voltage | 230/400V |
Rated Current | 1-63A |
Breaking Capacity | 4.5kA/6kA |
Protection Function | Overload and short circuit protection |
Curve Type | C/B D can be customized |
Mechanical Life | 20000 Times |
Installation | 35mm DIN Rail |
Ambient Temperature | -20℃~+70℃ |
Relative Humidity | ≤95% |
Color | Customized |
Green means closed，line disconnected.
1.Twenty years of experience in foreign trade,we have sufficient talent and resources in foreign trade exports , and have successively exported to overseas countries.
2.OEM/ODM:Strong R&D and design team to meet different customization needs..
3.After sale services: 2yrs warranty, product global liability insurance.
- If the above model is not suitable for your workpiece, please tell us your need and then we can send you the most satisfying drawing.
