CE ROHS NK-RT 50*50 ABS Plastic White Round Type Waterproof IP55 Junction Box Electrical

Categories	Junction Box
Brand	NAAKUU Electrical Equipment Manufacturer
Model	NK-RT 50*50
Body Material：ABS	N.Weight：11.7
IP:55	Installation：Inside，Outside
Hole Qty：4	Certificates：CE,ROHS
Terms of Payment	L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Update Time	Nov 18,2024

Contact Now

Favorites

Detail Information

Product Introduction

NK-RT 50×50

Waterproof Junction Box

Body material: ABS

Material characteristics: Impact, heat, low temperature and chemical resistance, excellent electrical performance and surface gloss, etc.

Certificates: CE, ROHS

Application: Suitable for indoor and outdoor electric, communication, fire fighting apparatus, iron and steel smelting, petrochemical industry, electron, power system, railway, building, mine, air and sea port, hotel, ship, works, waste water treatment equipment, environmental equipment and so on.

Installation: 1, Inside: There are the installation holes in the base for circuit board

or din rail.

2,Outside: The products can be directly fixed on the wall or other flat boards with screws or nails via the screw holes in the base.

Outlet hole: The plastic plate in the hole can be knocked off and installing cable gland to get better waterproof performance.

Product Parameter

Model Code	Outside Dimenstion			Hole Qty	Hole Size	G.Weight	N.Weight	Qty/Carton	Carton Dimenstion	IP
Model Code	L	W	H	Hole Qty	Hole Size	G.Weight	N.Weight	Qty/Carton	Carton Dimenstion	IP
NK-RT 50*50		50	50	4	25	12.9	11.7	300	45.537.551	55
NK-RT 80*50		80	50	4	25	13.1	11.8	240	533562	55
NK-RT 858550	85	85	50	7	25	15.6	14.4	200	453753	55
NK-RT 10010070	100	100	70	7	25	14	12.5	100	574635	65
NK-RT 15011070	150	110	70	10	25	13.6	12.3	60	6231.546.5	65
NK-RT 15015070	150	150	70	8	25	14.4	12.9	60	79.531.546	65
NK-RT 20010070	200	100	70	8	25	15.4	13.8	60	574342	65
NK-RT 20015580	200	155	80	10	36	13.6	11.9	40	64.540.541	65
NK-RT 20020080	200	200	80	12	36	16	14.4	40	854340.5	65
NK-RT 25520080	255	200	80	12	36	20	18	40	51.841.279.2	65
NK-RT 255200120	255	200	120	12	36	19.8	18	30	625362	65
NK-RT 300250120	300	250	120	12	36	19.7	17.8	20	615261.5	65
NK-RT 400350120	400	350	120	16	36	14.8	13.1	10	724161.5	65

1.ABS Material

—

The ABS material possesses characteristics such as impact resistance, heat resistance, low-temperature resistance, excellent
chemical resistance, superior electrical properties, and a good surface gloss.

2.Reserved Hole Mark

—

Depending on the size of the wires, you can choose to use the existing plugs in the reserved holes or use waterproof clamping connectors for optimal waterproofing effects.

3.Waterproof Seal Ring

— Good corrosion resistance, waterproof more durable.
